Update the database for searching properties and descriptions

It has been updated the database for searching properties, two main improvements:

  1.  Performance (now it is a database query instead of the former static file)
  2.  The reference model of the property
  3.  The format (uri, date-time, etc) for string properties.



Alpha version of the service for generating an NGSI-LD payload based on a Smart Data Model

This is an alpha version (so you can expect errors and not being complete). Use it at your own risk. Please report errors and suggestions at info@smartdatamodels.org

Call: https://smartdatamodels.org/extra/ngsi-ld_generator_v0.8.php

Parameters: (Mandatories)

  • schemaUrl: The link to the RAW version of the json schema (see example)
  • email: your email

Example: https://smartdatamodels.org/extra/ngsi-ld_generator_v0.8.php?schemaUrl=https://raw.githubusercontent.com/smart-data-models/dataModel.Streetlighting/f56f5a7933ab05d7fce1d5adc0847f25a099cdb4/StreetlightModel/schema.json&email=alberto.abella@fiware.org

Use any data model from Smart Data Models initiative and paste it into the form. Then you’ll get a page with a random payload compliant with the data model. Refresh for more.

You can also use this form

    This form generates a NGSI-LD payload compliant with a json schema from Smart Data Models.


    Email


    By using this form you agree with the storage and handling of your data by this website.


    After clicking it will appear a message confirming the submission

    It will take a while to redirect to the feedback on a specific page

    Thanks for being patient

    Script for checking a data model submission

    In the directory utils of the umbrella repository data-models there is a new python script that checks if a schema is properly documented and if the payload is correctly located and validates against the schema.

    New option for drafting a data model

    In the front page, there is a new option that allows you top to directly create a copy of the template sheet for creating new data models.

    Remember that this spreadsheet is done for those unfamiliar with json schema (the official format for the smart data models) to allow them to create a new data model from their knowlege.

    The use instructions are in the spreadsheet

    Any doubt please let us know at info@smartdatamodels.org



    Updated context.jsonld

    The context.jsonld for smart data models has been updated to meet json ld requirements. Now they are implementing geojson requirements.
    It affects the terms of bbox and coordinates. It could impact those elements having a geoproperty (most of the data models).

    Create your data model with a google spreadsheet

    This is a resource especially for those who have limited knowledge of JSON schema.

    If you want to create a basic version of a data model (not all JSON schema is implemented), you can use a copy of this spreadsheet as template. This spreadsheet is always available at https://bit.ly/schema_sheet short name.

    You need to fill the blue cells for these parameters:

    • Subject: Official Subject where this data model should be allocated. (Check the official list)
    • DataModel: Official data model name (Only one word i.e. WeatherForecast, no _).
    • Title: use to be the name data model name with spaces. (i.e. Weather Forecast)
    • Global Description: General text description of the data model. (2 lines is nice)
    • Property name: Exactly this, the name of the property. Use camelCase. It would be good to check here whether this property already exists (you can copy and paste). Use those you need and leave one empty after those you filled. Properties below an empty property name are ignored.
    • NGSI type: (Property, Relationship or Geoproperty)
    • Data type: Type of data in the property. (array and object are not fully implemented)
    • Other restrictions: If you are unfamiliar with JSON schema leave it empty.
    • Description: Official description of the property.

    Once you’ve got the schema, grab some examples (It is always good to review the contribution manual) and you can make a Pull Request on any of the subjects of any domain in Github. Or just use this form.

    NOTE 1: The first option will be attended quicker than the second.

    NOTE 2: Do not write out of the blue cells (it will be ignored). And do not add or remove cells. The converter script looks for these precise locations in blue.

    NOTE 3: Your spreadsheet has to be made public. (anyone with the link), otherwise, the script will not be able to retrieve your data.

    Call:

    Parameters: (Mandatories)

    Example: https://smartdatamodels.org/extra/generator_schema_from_any_sheet.php?sheetUrl=https://docs.google.com/spreadsheets/d/1TwXCBI-oedpf9RYpYlLNZnz5Pxl6o6kxHXKINRdJi5c

    Output: A json schema based on the properties defined in the database. This is an alpha version so errors are not managed.

      This form generates a json schema based on the properties of a google sheet (Based on this template)



      By using this form you agree with the storage and handling of your data by this website.


      After clicking it will appear a message confirming the submission

      It will take a while to redirect to the feedback on a specific page

      Thanks for being patient

      Alpha version for drafting a data model

      In case you are not an expert for creating a JSON schema (one of the elements of a data model)
      On this page, you have a spreadsheet for helping with the first steps.


      1.- Fill the spreadsheet with the names of the properties for your model

      2.- fill the NGSI type (Property, Relationship or Geoproperty)

      3.- In case of property, fill the data type (array and object types are currently not completely supported)

      4.- Fill in the description

      5.- Click the button, the page will reload

      6.- voila! you have your json schema below the spreadsheet, just copy and paste into your favourite editor.

      The python code for it is also made public in the utils directory in the data models repo.

      Include levels of privacy of properties in their description

      The privacy of the data contained in a property has been under discussion for the documentation of any property.

      Now there is a first version on how to implement it.

      The contribution manual has been updated for this possibility. See the specific slide about it.

      Privacy clause: Privacy:’[high/medium/low]

      Describes if the property has any kind of information related with personal data. Current options:

      • No clause: (default) this property does not contain personal data
      • Privacy:’high’: Those properties that refer to data on ideology, union affiliation, religion, beliefs, racial origin, health or sexual life.
      • Privacy:’medium’. Those properties related to the provision of financial solvency and credit services of people and those that contain definition of characteristics or personality and that allow evaluating certain aspects of personality or behavior of people.
      • Privacy:’low’.  Those properties that contains personal data different from the rest of types.

      Example:

      “refUserDevice” :{

      “description”: “Property. Model:’http://schema.org/Text’. Privacy:’low’. An object representing the current device used by the User.”.
